POWER MANAGEMENT MODULE
POWER MANAGEMENT MODULE, USED TO CONTROL OR TURN ON AND OFF A LOAD UNDER THE CONTROL OF THE OVERLOAD PREVENTION CONTROL BOARD IN THE TRANSFER SWITCH, KIT IS COMPRISED OF A POWER MANAGEMENT MODULE AND 24VAC CLASS 2 POWER SUPPLY TRANSFORMER, THE PMM CONSISTS OF A 2 POLE N.O, RELAY MOUNTED IN AN ENCLOSURE, THE 2 POLE RELAY IS RATED TO CONTROL:CURRENT-50A RESISTIVE OR 40A INDUCTIVE, VOLTAGE-600VAC, MOTOR RATING-7-1/2 HP @ 240 VAC, LRA-240A @ 240VAC, COIL VOLTAGE-24 VAC (6.5 VA HOLDING), THE ENCLOSURE IS NON-METALLIC AND IS RATED UL TYPE 3R,
WEIGHT:1 LBS 12 OZ,
Product Information
Product Information
Shipping & Returns
Shipping & Returns
POWER MANAGEMENT MODULE
POWER MANAGEMENT MODULE
POWER MANAGEMENT MODULE, USED TO CONTROL OR TURN ON AND OFF A LOAD UNDER THE CONTROL OF THE OVERLOAD PREVENTION CONTROL BOARD IN THE TRANSFER SWITCH, KIT IS COMPRISED OF A POWER MANAGEMENT MODULE AND 24VAC CLASS 2 POWER SUPPLY TRANSFORMER, THE PMM CONSISTS OF A 2 POLE N.O, RELAY MOUNTED IN AN ENCLOSURE, THE 2 POLE RELAY IS RATED TO CONTROL:CURRENT-50A RESISTIVE OR 40A INDUCTIVE, VOLTAGE-600VAC, MOTOR RATING-7-1/2 HP @ 240 VAC, LRA-240A @ 240VAC, COIL VOLTAGE-24 VAC (6.5 VA HOLDING), THE ENCLOSURE IS NON-METALLIC AND IS RATED UL TYPE 3R,
WEIGHT:1 LBS 12 OZ,
$30.00
POWER MANAGEMENT MODULE—
$30.00
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
POWER MANAGEMENT MODULE, USED TO CONTROL OR TURN ON AND OFF A LOAD UNDER THE CONTROL OF THE OVERLOAD PREVENTION CONTROL BOARD IN THE TRANSFER SWITCH, KIT IS COMPRISED OF A POWER MANAGEMENT MODULE AND 24VAC CLASS 2 POWER SUPPLY TRANSFORMER, THE PMM CONSISTS OF A 2 POLE N.O, RELAY MOUNTED IN AN ENCLOSURE, THE 2 POLE RELAY IS RATED TO CONTROL:CURRENT-50A RESISTIVE OR 40A INDUCTIVE, VOLTAGE-600VAC, MOTOR RATING-7-1/2 HP @ 240 VAC, LRA-240A @ 240VAC, COIL VOLTAGE-24 VAC (6.5 VA HOLDING), THE ENCLOSURE IS NON-METALLIC AND IS RATED UL TYPE 3R,
WEIGHT:1 LBS 12 OZ,
